Outdoor Straight Stair Lift
The Pilot Aviator E603
The Pilot e603 is an outdoor stairlift designed to provide safe and reliable mobility assistance for people with limited mobility who need to navigate stairs outside their home. It features a weather-resistant design, with a waterproof cover to protect against the elements, and a battery-powered motor to ensure continuous operation even during power outages.
The entire frame is powder-coated. The gear rack is also powder coated for extra protection from the elements. The upholstery colors withstand the UV rays from the sun. To further add protection, Each unit comes with a durable cover to store your stair lift from the elements when not in use. Each unit comes standard with two radio frequency remote controls. This allows you to move the outdoor straight stair lift from inside your home or your car, keeping you protected from the weather. You can even use the remotes to haul groceries, boxes, or laundry upstairs safely and conveniently.
With a 350 lb. weight capacity, the Pilot Aviator E603 Outdoor Stair Lift has the drive to handle most people.
VERSATILITY
• Adjustable armrest width & seat height.
• 2 position swivel seat for safe transfers.
FUNCTIONALITY
• The unit charges the batteries for you.
• Sleep mode feature reserves power during outages.
COMFORT
• Stylish design, affordable solution without comprising on safety.
COMPACT DESIGN
Only 13″ wide when folded
4 UPHOLSTERY COLORS AVAILABLE
REMOTE CONTROLS
Work with cover on or off
The stairlift is also equipped with safety features such as a seat belt and a swivel seat for easy entry and exit. Overall, the Pilot E603 is a practical solution for anyone who needs help navigating outdoor stairs.
SAFETY IS THE STANDARD
• 5 directional safety sensors
• Retractable seat belt
• Armrest position sensors
• Seat position sensor
• Over speed governor
• Electro mechanical brake
• Key switch
DIAGNOSTICS DISPLAY
• Displays codes for all functions
• Quick Troubleshooting
• Communicates Power Failures
• Safety Edge Sensor Codes
OUTDOOR OPTIONS
The Outdoor E603 has been completely weatherized with galvanized components & powder coating.
Each unit Is supplied with:
• 2 lockboxes for storing the remotes
• A weatherproof charger box
• Fabric cover to protect from weather
T E C H N I C A L S P E C I F I C A T I O N S
• Weight capacity 350lbs / 120Kg
• Motor 950W, 24VDC
• Speed 20-fpm~ 6M/min
• Drive Method Rack & Pinion
• Incline Limits 0~52°
• Charger 115~230V AC, 50/60Hz
• Battery 24VDC re-chargable batteries
• Internal Arm Rest Width 16″ – 20″
• Seat to Footplate Height 17″ – 20″
• 2 Remote Controls included
• Overtravel prevention, motor brake,
• key switch, retractable seat belt,
• armrest & swivel seat safety switches
• 5 years on the mottor gear box
• 2 years on components
17 years Experience
Serving the following Texas Counties: Anderson, Archer, Bosque, Bowie, Camp, Cass, Cherokee, Clay, Colin, Comanche, Cooke, Dallas, Delta, Denton, Ellis, Eastland, Erath, Fannin, Franklin, Freestone, Grayson, Greggs, Hamilton, Harrison, Hill, Hood, Hopkins, Hunt, Jack, Johnson, Kaufman, Lamar, Limestone, Marion, McLennan, Montague, Morris, Navarro, Palo Pinto, Panola, Parker, Rains, Red River, Rockwall, Rusk, Shelby, Smith, Somervell, Stephens, Tarrant, Titus, Upshur, Van Zandt, Wichita, Wise, Wood, and Young County.
Now Offering Stairlift Sales & Service in Austin, San Antonio, and Corpus Christi.
Greater Houston or Galveston area – See GreaterHoustonStairLifts.com
How to Store Your Stair Lift
In this position it is easier to fold the arms and seat.
Gently lift both arms upright.
The seat smoothly lifts into the folded position.
Using the lever closest to you, rotate the seat back to the riding position while the arms and seat are upright.
The footrest folds with ease. Use your foot or a cane to fold it for safe measures.
Place the durable outdoor cover over the unit when not in use for the best protection from the weather.
1 Year Labor Warranty on New Installations
Our tech team will assist you over the phone free 7 days / week. If repair is required, a service technician will call before arriving to your location.
• Free Home Evaluations
• Next Day Installations
• Local Repair Service
• Call 7 Days / Week
• Stay in Your Home
• Lowest Prices
The CSA mark demonstrates to our customers, that our product has been certified to applicable standards including standards written or administered by the American National Standards Institute (ANSI), Underwriters Laboratories (UL), CSA Group (CSA), NSF International (NSF), and other North American and global organizations.
